Shower Glass Drilling Machine A66

Product Features:

This equipment is used for processing shower room glass and is the first choice for processing scattered orders of shower room glass.
This equipment can be used as a standalone unit or connected with edging machines, cleaning machines, etc., to form an automated production line.
The operation interface of this equipment is a computer-based interface.
It can read information via online barcode scanning and automatically perform hole distribution/drilling.
It can be connected to ERP systems and support online drawing and importing of drawings.

Online Message Get a Quote

Product overview

Shower Glass Drilling Machine A66

The equipment can operate as a standalone unit or be integrated with glass deep processing equipment such as loading and unloading tables to form an automated production line. It also features functions including bar code information reading, automatic hole distribution and drilling, ERP system integration, and online drawing and importing. These capabilities meet the needs of large-scale and intelligent glass drilling processing, and it is widely used in the deep processing of architectural glass and shower room glass.

Product parameters

Processing range: X:0-2500; Y1/Y2:0-1100mm

Drilling diameter: Φ6-Φ50mm

Glass thickness: 4-19mm

The speed of screw propulsion: 0-3mm/s

The height of the table:900+/-20mm

Overall size:8600*4600*2200mm

The max glass size:2500mm*1500mm

The min glass size:1200mm*300mm

Application Areas & Scenarios
